AGP High Frequency Ring Saw HR16

Description

400 mm wet ring saw with 6600 W high frequency permanent magnet synchronous motor for up to 300 mm depth of cut.

• Patented One Step Drive Tensioner makes fast and easy blade adjustment and keeps tension equalized.
• Change saw blade quickly and without disassembly of the cover.
• High Stability Guide Roller design keeps the blade stable and centralized when beginning the cut.
• LED Indicator Indicates load conditions
  (electronic & thermal protection).
• Flexible upper and bottom splash guards prevent splashing slurry.
• Hall Effect Switch is completely waterproof and dustproof.
• Water feed system with fine adjustable flow and quick release coupling.

Power:
6600 W (3~380-480 V)

Max. Capacity:
300 mm Depth of Cut

Type:
Wet only

• Model
• HR16
• Power Input:
• 3~380-480 V : 6600 W
• No Load Speed
• 2500 /min
• Linear Speed
• 53 m/s
• Blade Diameter
• 400 mm (15-3/4″)
• Max. Cutting Depth
• 300 mm (11-13/16″)
• Soft Start & Overload Protection
• With
• Cable Length
• 6m
• Dimensions (L x W x H)
• 780 x 290 x 500 mm
• Weight
• 13.2 kg (29.1 lb)
